2D Shop Drawing Production and CAD with Bar Bending Schedule (BBS)

In modern-day construction, precision and efficiency are paramount. Shop drawings and bar bending schedules (BBS) are fundamental components in reinforced concrete and steel structures, guaranteeing accurate fabrication and installation of every element.

MOSAIC Ecoconstruction Solutions specializes in Eurocode-compliant structural detailing, incorporating the Singapore Annex to meet local regulatory requirements. This guide explores the critical aspects of shop drawing detailing and bar bending schedules, helping contractors, engineers, and project managers avoid costly errors and delays.

What Are Shop Drawings and Bar Bending Schedules?

1. Shop Drawings

Shop drawings are highly detailed and dimensioned documents that convert design concepts into executable guidelines for contractors, fabricators, and installers. They provide exact measurements, material specifications, and technical details essential for structural, architectural, and MEP (Mechanical, Electrical, and Plumbing) systems.

Sample shop drawing from our one of the recent projects





A detailed shop drawing of a steel structure showcasing precise dimensions, annotations, and fabrication details.

2. Bar Bending Schedules (BBS)

A Bar Bending Schedule (BBS) is a detailed document outlining the specifications of reinforcement bars in reinforced concrete structures. It defines rebars’ shape, dimensions, quantity, and positioning, facilitating precise fabrication and efficient installation.

Both documents are essential for error mitigation, waste reduction, and adherence to design standards, including the Eurocodes.

Bar Bending Formulas

Bar Bending Schedule (BBS) Format

Why Are Shop Drawings and Bar Bending Schedules Important?

1. Ensuring Construction Accuracy

• Shop drawings translate design intent into executable instructions for contractors.
• Bar bending schedules provide precise reinforcement details, minimizing material waste.

2. Compliance with Eurocode & Singapore Standards

• EN 1992 (Eurocode 2) governs concrete structures.
• BCA (Building and Construction Authority) mandates strict adherence to reinforcement detailing.

3. Reducing Rework and Delays

• Errors in shop drawings or BBS can lead to costly rework, delays, and structural failures.
• Proper detailing ensures seamless fabrication and assembly.

4. Enhancing Cost Efficiency

• Accurate BBS reduces steel wastage (up to 5-10% savings).
• Optimized shop drawings prevent miscommunication and on-site modifications.

Key Elements of Shop Drawing Detailing

1. Structural Alignment with Design Drawings

✔ Verify that shop drawings match architectural and structural plans.
✔ Cross-check dimensions, elevations, and connections.

2. Material Specifications

✔ Steel grade (e.g., B500B as per Eurocode)
✔ Concrete cover requirements (as per Singapore’s CP 65)

3. Welding & Bolting Details

✔ Weld symbols, bolt types, and torque specifications must be indicated.

4. Clash Detection

✔ Use BIM (Revit, Tekla Structures) to detect conflicts between MEP, structural, and architectural elements.

5. Approval & Revision Control

✔ Ensure all shop drawings are stamped by a Professional Engineer (PE) before fabrication.
✔ Maintain a version control log to track revisions.

Critical Checks in a Bar Bending Schedule (BBS)

1. Rebar Shape Codes & Cutting Lengths

✔ Confirm bending angles, hook lengths, and lap splices comply with Eurocode EN 1992-1-1.

2. Bar Marking & Scheduling

✔ Each bar must have a unique mark number corresponding to the shop drawing.

3. Spacing & Lap Lengths

✔ Lap lengths must follow Eurocode 2 + Singapore Annex modifications for seismic zones.

4. Weight & Quantity Calculations

✔ Ensure total steel tonnage matches the bill of quantities (BOQ) to prevent shortages.

5. Special Reinforcement Details

✔ Shear links, column ties, and confinement reinforcement must be detailed.

Common Mistakes to Avoid in Shop Drawings and BBS

1. Incorrect Interpretation of Design Intent

• Misinterpretation leads to fabrication errors and costly rework.
• Ensure that shop drawings match architectural and structural intent.

2. Failure to Check Overlaps and Conflicts

• Overlapping reinforcement bars can cause congestion and improper concrete compaction.
• Ensure clash-free detailing before execution.

3. Ignoring Structural Load Paths

• Improper detailing can weaken structural integrity.
• Validate load-bearing components to ensure they align correctly with structural requirements.

4. Neglecting Fabrication Constraints

• Bars that are too long may not fit into standard bending machines.
• Ensure that practical fabrication constraints are considered.

5. Disregarding Site Conditions

• Site-specific conditions should influence reinforcement detailing and cover depth.
• Consider climate, soil conditions, and exposure class.

Best Practices for Effective Shop Drawing and BBS Implementation

1. Early Coordination Between Stakeholders

• Conduct regular design reviews with architects, engineers, and contractors.
• Use Building Information Modeling (BIM) for clash detection.

2. Use Advanced Software for Precision

• Employ AutoCAD, Tekla, Revit, and Staad Pro for detailing.
• Utilize automated BBS generation tools to minimize errors.

3. Adopt a Standardized Review Process

• Follow a step-by-step approval process before execution.
• Ensure third-party validation and quality checks.

4. Training and Quality Assurance

• Train the site engineers and steel fixers to read and implement shop drawings.
• Implement rigorous quality control during fabrication and site work.

How MOSAIC Ensures Flawless Shop Drawings & BBS

✔ Eurocode-Compliant Detailing – Aligned with EN 1992 & Singapore Annex
✔ BIM & 3D Modeling – Clash-free coordination in Revit & Tekla
✔ PE-Stamped Approvals – Legally compliant submissions
✔ Automated BBS Software – Minimizes human error

Case Study: Avoiding an SGD 500K Rework Disaster

Project: High-rise condominium in Tanjong Pagar
Issue: Original BBS had wrong lap lengths, risking column failure.
Fix:

• Re-designed BBS per Eurocode 2 + Singapore Annex
• Saving SGD 500K in potential demolition costs



Formwork design, TEKLA view 3D



Sample rebar shop drawing with bar bending schedule



Rebar cutting & bending machines.



Conclusion: Precision Saves Time & Money

Shop drawings and BBS are critical in ensuring structural stability, construction efficiency, and cost optimization. At MOSAIC Ecoconstruction Solutions, we offer expert consultancy in shop drawing detailing and bar bending schedule preparation, ensuring:

• Precise and clash-free detailing.
• Compliance with international standards.
• Material and cost optimization.
• Seamless execution with minimal rework.

Contact us today to ensure error-free, efficient, and cost-effective construction solutions!
